- Pumps water only: Prevents pumping hydrocarbons in elevator sumps, containment areas, and vaults
- Oil/water discrimination: Sensor energizes when it detects water and shuts the pump down when it detects oil
- Stand-alone controller: Operates any pump up to 1 HP without expensive control panels
- Built-in differential: ON/OFF differential available in 2.5″ or 6″ models
- Flexible power options: Available in 120 VAC, 230 VAC 50/60 Hz., or 12/24 VDC
- Quick installation: Directly controls sump pumps 0 to 1 hp with optional piggyback
- Code & compliance support: Helps satisfy elevator code and environmental plans while reducing risk of fines and cleanup costs
IN STOCK. READY TO SHIP. PROBLEM SOLVED.
Got water where oil might be present? We keep water-only pump switches ready so you can protect sumps and vaults today—not weeks from now. Just ask.
OilSmart Sump Pump Switch Features
For elevator sumps, underground utility vaults, tank farms, secondary containment areas, & pits.
01
Design
- Water-only pumping: Will not pump hydrocarbons in elevator sumps, containment areas, and pits
- Sensor logic: Energizes a pump, valve, alarm or other device when it detects water—not oil
- Industrial grade: Stand-alone component or integral part of a pump assembly
02
OPERATION
- Direct control: Controls sump pumps from 0 to 1 hp (piggyback) for quick installation
- Built-in differential: 2.5″ or 6″ between ON and OFF for reliable cycling
- No panel required: Works without expensive electrical control panels
03
ELECTRICAL
- Multiple voltages: 120 VAC, 230 VAC 50/60 Hz., or 12/24 VDC
- Piggyback options: Available with or without a piggyback plug
04
COMPLIANCE
- Regulatory support: Helps satisfy elevator code ASME A17.1 and EPA Spill Prevention, Control, and Countermeasure Plan
- Where it’s used: Elevators, transformer oil containment areas, underground utility vaults, marine, and other industrial sumps
WHY OILSMART PUMP SWITCH MATTERS
Water and oil don’t mix in a sump. This switch differentiates between them, pumps water only, and helps meet code without costly panels or complex installs.
How the OilSmart Pump Switch Works
PUMPS WATER ONLY, WILL NOT PUMP HYDROCARBONS The Oil Smart Pump Switch, when combined with a non-auto sump pump, will allow water to be pumped without the risk of pumping oil. The switch is ideal for elevator sumps, transformer containment areas, parking garages, and city underground vaults.
The OilSmart™ water pump switch & sensor lets you safely pump water only! This switch energizes a pump, valve, alarm or whatever’s wired into it when it detects water, not oil. If it detects oil, it shuts the pump DOWN! It’s deadly effective and economical to use!
>Click Here For Product Brochure/Technical Sheet
The OilSmart Pump Switch is a stand-alone pump controller requiring no expensive pump control panels. It will operate any pump up to 1HP. All models include built-in ON and OFF differential of 2.5”or 6”. It is an industrial grade switch that differentiates between oil and water used to control pumps in elevators, transformer oil containment areas, underground utility vaults, marine, and other applications. The OilSmart Switch can be an integral part of the pump assembly or a stand alone component wired to the pump or a control valve. Since 1995, the Original and Patented OilSmart Switch has been the reliable choice for safely pumping water. Installation of the unit allows you to comply with State and Federal regulations while reducing the risk of adverse publicity, fines and expensive cleanup costs. How it Works
FEATURES
- Directly controls sump pumps 0 to 1 hp(piggyback): quick installation
- Available in 120 VAC, 230 VAC 50/60 Hz., or 12/24 VDC
- No expensive electrical panel required
- Sensors differentiate between oil and water
- Differential between on and off comes in 2.5″or 6″ models
- Available with or without a piggyback plug
- Helps satisfy elevator code ASME A17.1 and EPA, The Spill Prevention, Control, and Countermeasure Plan
APPLICATIONS
- Elevator Sumps
- Electric Utilities ( Substations, Power Plants, Underground Vaults, and Transformer Barriers
- Any Industrial Sump or Marine Application
Frequently Asked Questions
What does the pump switch do when it detects oil?
It shuts the pump down so hydrocarbons are not pumped.
Can the switch run without a separate control panel?
Yes, it is a stand-alone pump controller that requires no expensive pump control panels.
What pump sizes can it control?
It will operate any pump up to 1 HP.
What power options are available?
Models are available in 120 VAC, 230 VAC 50/60 Hz., or 12/24 VDC.
Does it help with regulatory compliance?
Installation helps satisfy elevator code ASME A17.1 and environmental plans while reducing the risk of fines and expensive cleanup costs.
