Marine Sanitation Device
Get a Quote
- USCG/IMO Certified – Ready to operate and built to last
- Rugged & Indestructible : Built with non-corrosive materials for life onboard
- Simple Install + Easy Retrofit : Compact low-profile design fits tight spaces
- No Odor, No Sludge : Aerobic biological system with no mess or smell
- Zero Moving Parts = Low Maintenance : Reliability at sea with fewer headaches
IN STOCK. READY TO SHIP. READY WHEN YOU ARE.
Need a USCG-certified MSD without the 12–16 week wait? Units are in stock so your vessel stays operational and ready to go — no delays.
Ask what’s available today.
Marine Sanitation Device Features
USCG/IMO-Certified Type II MSD – Reliable, Compact, Ready to Operate TheTankMSD delivers proven marine sewage treatment performance with a compact, low-profile design and rugged construction. Built for real-world use, it’s simple to install, easy to operate, and virtually indestructible.
01
Design
- Compact & low-profile: Fits easily in tight engine rooms or marine heads, ideal for retrofit applications.
- Rugged construction: Corrosion-proof, non-metallic materials ensure durability and long service life at sea.
- easy retrofit installation: Ships ready to install for minimal downtime.
- No moving parts: Zero mechanical components to maintain, reducing headaches and operational risk.
02
PERFORMANCE
- 3-stage aerobic treatment: Aeration, clarification, and disinfection deliver clear, odor-free water.
- Processes 56–110 gal/day: Capable of handling 4, 12, 16, 24, or 32 persons (24 and 32 via doubled-up units).
- Proven reliability: USCG/IMO-certified design that follows all EPA compliance requirements — suitable for overboard discharge or holding tank use.
- Black water management: Properly sized units handle sewage efficiently — ask us for guidance on selecting the right system.
03
INSTALLATION
- Minimal maintenance: No consumables or internal pumps required.
- Low utility draw: Aeration system runs on standard 110V; alternate voltage air pumps available on request.
- EatsCRAP Bio Supercharger™: Required for ongoing performance — reduces odor and keeps the aerobic biological system at peak efficiency.
- Inspection-friendly: Simple access for cleaning and system checks.
WHY THE TANK MSD MATTERS
When space is tight and reliability matters, TheTankMSD delivers proven marine sanitation performance without the hassle. Built for real-world marine use—no tuning, no babying, just results.
TheTankMSD Economy Type II Marine Sanitation Device is a biological aerobic (bacteria and air) marine sewage treatment system. Liquid and solid wastes are removed from the water by bacteria naturally contained in sewage.
With a low profile, compact design, and easy retrofit install, this USCG-approved MSD is solid, simple, and built with quality components. It’s virtually indestructible and corrosion-proof, available in stock now for 4, 12, 16, and 32 person capacities.
“The poop plant – the real deal! No frills — no BS!”
How It Works: 3-Stage Treatment Process
1. Aeration
Sewage is aerated as it enters, mixing with bacterial sludge and air from non-clog diffusers. Aerobic bacteria consume the sewage, preventing solids from settling.
2. Clarification
The aerated liquid flows upward through biological filter media, where sticky biofilms trap and digest particles. The clarified water is now clear and ready for disinfection.
3. Disinfection
Chlorine tablets mix with the clarified liquid for final disinfection. Output can be discharged overboard or routed to a holding tank for use in No Discharge Zones.
Models & Specs
| TheTankMSD | TTM #400 | TTM #1200 | TTM #1600 |
|---|---|---|---|
| Persons | 4 | 12 | 16 |
| Length | 41" | 56" | 76" |
| Width | 15" | 22" | 22" |
| Height | 17" | 17" | 17" |
| Dry Weight | 42 lbs | 76 lbs | 90 lbs |
| Wet Weight | 295 lbs | 575 lbs | 850 lbs |
| USCG Approval Nos. | Provided with unit | Provided with unit | Provided with unit |
MSD Brochure and Technical Data / How TheTankMSD Works / MSD Pump-Out System / Marine Throne Macerator Toilet
Key Features
- USCG/IMO Certified Type II MSD – Fully approved and ready to operate
- Rugged & Indestructible – Corrosion-proof, non-metallic materials
- Simple Install + Easy Retrofit – Fits tight spaces, minimal downtime
- No Odor, No Sludge – Aerobic biological system keeps water clear
- Zero Moving Parts – Low-maintenance reliability at sea
- Processes 56–110 gal/day – Handles 4, 12, 16, 24, or 32 persons (24 and 32 via doubled-up units)
- Low Utility Draw – Aeration system runs on standard 110V; alternate voltage air pumps available on request
- EatsCRAP Bio Supercharger™ – Required for ongoing performance: reduces odor and keeps system at peak efficiency
Note on Gray Water
Gray water cannot be used in an MSD unit — it will overload the system. MSDs are designed for black water (sewage) only.
Add-On: EatsCRAP Bio Supercharger™
Reduces odor and keeps your system operating efficiently. Works with all Type II MSDs.
Learn more about EatsCRAP
Applications
- Commercial Workboats
- Tugboats & Ferries
- Fishing Vessels
- Military Vessels
- Offshore Platforms
- Yachts & Charter Fleets
- Research Vessels
- Uninspected Vessels in NDZs
Frequently Asked Questions
What is a Type II Marine Sanitation Device (MSD)?
A Type II MSD is a USCG- and IMO-certified marine sewage treatment system. It uses aerobic bacteria and aeration to process sewage, producing clear, disinfected water suitable for overboard discharge or holding tanks in No Discharge Zones.
Do these units require pumps or consumables?
No internal sewage pumps or consumables are required. The system runs on low 110V power and is designed for minimal maintenance with no sludge build-up.
Can TheTankMSD handle gray water?
Only if the system is properly sized for it. Introducing gray water to an undersized MSD can overload the system and affect performance. SkimOIL® can help you select the right size for your application.
Are these MSDs corrosion- and odor-proof?
Yes. TheTankMSD is built with non-corrosive materials and an aerobic biological process that eliminates sludge and odor, making it ideal for long-term marine operation.
Are there any add-on enhancements?
Yes. The EatsCRAP Bio Supercharger™ reduces odor and helps keep all Type II MSDs operating efficiently and running at peak performance.
TheTankMSD is not just a treatment tank — it's peace of mind.
- USCG-certified, odor-free, corrosion-proof, compact, and ready to ship. Keep your vessel inspection-ready and operating with confidence.
