- Eliminates water and dirt: Keeps diesel fuel clean by removing contaminants before they reach your engine
- Automatic recirculation: Continuously purifies fuel on a scheduled basis to ensure readiness
- Filter-less separator: Uses a patented system to remove water and solids without disposable filters
- UL-listed controller: System includes separate NEMA 4 PLC controller for reliable automation
- Skid or panel options: Adaptable to tight spaces or mobile deployment needs
- Designed for modern fuels: Works with ultra-low sulfur diesel (ULSD) and current fuel standards
- No moving or wear parts: The core purifier design ensures minimal maintenance
- Prevents generator failures: Keeps emergency power systems running with clean, reliable fuel
IN STOCK. READY TO SHIP. PROBLEM SOLVED.
Fuel issues don’t wait, and neither should you. We build these systems to keep your diesel clean and your generators running—because uptime matters.
Fuel Tank Recirculating Filter System Features
The Fuel Tank Recirculating Filter System (FTRFS) is a packaged system incorporating the patented Diesel Fuel Purifier, filter-less filter / separator. These recirculating systems are purpose designed specifically for your fuel tanks, application and conditions, to keep fuels free from dirt and water by keeping up with the contamination instead of trying to catch up with it.
01
Performance
- 5–50 GPM flow rates: Suited for a wide range of tank sizes and diesel demands
- 99.5% coalescing efficiency: Optional three-phase system for superior moisture removal
- Continuous-duty pump: Built for reliability in demanding applications
02
Design
- Modular flexibility: Choose from single-tank, duplex pump, or multi-tank configurations
- Skid and panel options: Fits irregular or confined spaces
- Stainless-steel fittings: Corrosion-resistant components built to last
03
AUTOMATION
- Preprogrammed PLC: Automated fuel polishing without user intervention
- Dialysis-style recirculation: Designed to keep up with contamination, not just react to it
WHY FTRFS MATTERS
If you rely on diesel generators, your fuel can’t fail when it matters most. This system ensures your fuel stays clean—automatically—so your power is ready anytime, anywhere.
Overview: Why Clean Fuel Matters
The Fuel Tank Recirculating Filter System (FTRFS) is a packaged system incorporating the patented Diesel Fuel Purifier, filter-less filter / separator. These recirculating systems are purpose designed specifically for your fuel tanks, application and conditions, to keep fuels free from dirt and water by keeping up with the contamination instead of trying to catch up with it. If you have diesel generator equipment…you have to keep your fuel in good shape……or you’re NOT going to be generating power.
The FTRFS automatically recirculates and polishes fuel at given flow rate (2-50 GPM), for a single storage tank on a preprogrammed schedule and includes the SkimOIL ® Universal Fuel Purifier (TFP series), an optional three-phase 99.5% efficient fuel coalescer, and a high-efficiency fuel filter, and comes equipped with a continuous-duty motor and fuel pump, stainless-steel fittings and a separate UL-listed PLC controller in a NEMA 4 enclosure.
Modern systems for modern fuel requirements. FTRFS systems can be designed for use with ultra-low-sulfur diesel (ULSD) fuel. Duplex pump units (DPU) and multi-tank units (MTU) are also available. Programmable purification systems from SkimOIL ® can be configured to meet your diesel fuel operation and diesel fuel quality requirements. From permanently installed automated systems to skid solutions that can be transported and set in place rapidly to polishing panels to fit irregular or tight areas, SkimOIL ® has programmable fuel cleaning solutions.
Need generator power ? You’ll be needing clean fuel for that!
How It Works: Dialysis-Style Purification
From day 1 after after fuel delivery, your diesel fuel starts deteriorating due to any water already in your tank and more that came in with the fuel. The Fuel Tank Recirculating Filter System (FTRFS) keeps the fuel ready to use, eliminating water, heavy solids and bio-junk before they get to your primary filters.
We still suggest you install an individual fuel purifier (TFP) in-line between the fuel tank or day tank and the diesel engine / generator to remove any moisture or contaminants before they enter the engine fuel system.
The Fuel Tank Recirculating Filter System (FTRFS) is designed to KEEP UP with the water, dirt and algae………..by recirculating and cleaning purifying your fuel on a dialysis basis. KEEPING UP WORKS ——CATCHING UP DOES NOT!
See the “FUEL DOCTOR” VIDEO that shows exactly how the diesel fuel purifier works. It’s so simple and efficient and has NO MOVING or WEAR PARTS. Sizes for all engines & fuel delivery systems.
Who Needs Clean Generator Fuel?
WHO NEEDS TO HAVE THEIR GENERATOR FUEL TANKS CLEANED?
Well….how about anyone and everyone who uses generator power?
Telecommunication centers, hospitals, emergency clinics, first responders, phone centers, schools, labs, medical centers, rehab centers, large shopping centers, research facilities, ski resorts, senior community centers, dialysis facilities, surgical centers, nursing homes, assisted living facilities, 911 call centers, EMT’s, police communications, aquariums, zoos, parking structures, pump stations, lift stations, waste water treatment plants (WWTP – POTW)…who else?
See our PTCU Portable Tank Cleaning Unit See The Fuel Purifier
Click the links below for the specification sheet…
Frequently Asked Questions
What does the FTRFS system remove from diesel fuel?
It removes water, heavy solids, and biological contaminants like algae before they reach the engine.
How does the system operate?
It automatically recirculates fuel on a preprogrammed schedule using a PLC-controlled pump and purifier.
Can it work with ULSD fuel?
Yes, the system is designed for compatibility with ultra-low sulfur diesel (ULSD).
Does the system require filter replacements?
No, it uses a patented filter-less separator that removes contaminants without disposable filters.
Who should use a fuel recirculating system like this?
Anyone using generator power—such as hospitals, telecom centers, emergency facilities, and more.
